Different Types of Fire Pumps for Enhanced Fire PrOTECTION
End Suction Fire Pumps
End suction fire pumps are versatile and cost-effective. They feature a single-suction impeller and are commonly used in smaller fire protection systems, including residential and small commercial buildings. Fire pump supplier
Vertical Split-Case Fire Pumps
Vertical split-case fire pumps are similar to their horizontal counterparts but are vertically oriented. They are often used in situations where space is a constraint, such as high-rise buildings and compact mechanical rooms. Fire pump supplier
Vertical In-Line Fire Pumps
Vertical in-line fire pumps have a compact design and are installed within the piping system, saving space and simplifying installation. They are ideal for buildings with limited mechanical room space. Fire pump supplier
Horizontal Split-Case Fire Pumps
Horizontal split-case fire pumps are commonly used in fire protection systems. They are known for their efficiency and ease of maintenance. These pumps have a horizontally split casing, making them suitable for various applications. Fire pump supplier
Vertical Turbine Fire Pumps
Vertical turbine fire pumps are submerged in a water source, such as a well or reservoir. They are commonly used in areas with below-ground water sources, like underground storage tanks. Fire pump supplier
CENTRIFUGAL FIRE PUMPS END SUCTION
CENTRIFUGAL FIRE PUMPS END SUCTION
CENTRIFUGAL FIRE PUMPS VERTICAL TURBINE
CENTRIFUGAL FIRE PUMPS END SUCTION
- Top Centerline Discharge
- Foot Supported Casing
- Back Pullout Design
- Self- Venting Design
- Efficiently Designed Impeller
- Frame-Mounted Design
- Small Footprint Ideal for Retrofit
- Dynamically Balanced Impeller
- Heavy Duty with Heavy Wall Thickness
- 100% Hydrostatic & Performance Tested
- Back Pump out Vanes
Fire pump supplier
Casing Cast Iron / Ductile Iron
Impeller Bronze / Duplex (upon request)
Shaft Alloy Steel / Stainless Steel / Duplex (upon request)
Capacity 50GPM to 1000 GPM
Pressure 65 to 234 PSI
Max. Working Pressure 180 to 315 PSI
Speed 2900, 3000, 3500 and 3600 RPM
CENTRIFUGAL FIRE PUMPS SPLIT CASE
CENTRIFUGAL FIRE PUMPS VERTICAL TURBINE
CENTRIFUGAL FIRE PUMPS END SUCTION
- Volute Type Thru-Bore Casing
- Frame-Mounted Design
- Small Footprint Ideal for Retrofit
- Heavy Duty with Heavy Wall thickness
- 100% Hydrostatic & Performance Tested
- Dynamically Balanced Double Suction Impeller
Fire pump supplier
Casing Cast Iron / Ductile Iron, Impeller Bronze / Duplex (upon request) , Shaft Alloy Steel / Stainless Steel / Duplex (upon request)
Capacity 150GPM to 3500 GPM , Pressure 88 to 335 PSI , Max. Working Pressure 220 to 410 PSI, Speed 2900, 3000, 3500 and 3600 RPM
CENTRIFUGAL FIRE PUMPS VERTICAL TURBINE
CENTRIFUGAL FIRE PUMPS VERTICAL TURBINE
CENTRIFUGAL FIRE PUMPS VERTICAL TURBINE
- Designed and built as per UL 448 and NFPA20
- Dynamically Balanced Impeller
- Constructed in variety of metallurgies
- Available 50Hz and 60Hz
- Drivers with gear boxes at electrical and diesel speed
- Open line shaft
- Packaged systems available
- Self-Venting Design eliminates vapor lock
- Efficiently Designed Shaft
- Heavy wall thickness
- Sealing arrangement is packing design
- Modular Construction
Fire pump supplier
Capacity 200GPM to 2000 GPM, Pressure 40 to 359 PSI, Max. Working Pressure 290 to 395 PSI, Speed 1450, 1480, 1760, 1780, 2900, 2980, 2950 & 3000 RPM
FIRE PUMP SKID SUPPLIER
DIESEL DRIVEN & ELECTRICAL MOTOR
In the competitive landscape of engine-driven centrifugal fire pump skids, AL ADRAN stands tall as your premium choice. We understand the critical importance of fire protection and have specialized in delivering top-notch packages that align with NFPA 20 requirements, boasting Listed & Approved Drivers for unparalleled performance. Fire pump supplier
The Ultimate Fire Protection Solution
Listed Centrifugal Fire Pump Skids - Meeting All Your Needs
When it comes to safeguarding your property against the ravages of fire, compromise is not an option. AL ADRAN proudly offers a range of listed centrifugal fire pump skids designed to cater to every fire protection need. With us, your safety is our priority.
Powered by Excellence
Our centrifugal fire pump skids are driven by Listed & Approved Diesel Engines and Electric Motors. These powerhouses ensure optimal reliability and efficiency, guaranteeing that your fire protection system performs at its peak when you need it most.
Rigorous Testing & Precision Engineering
Pre-Tested Skid Packages for Unwavering Reliability
Before our skid packages reach your hands, they undergo meticulous pre-testing and thorough inspections. We leave no room for error, ensuring that every component is in perfect working order. Your peace of mind is our commitment.
Perfect Alignment for Direct Operation
Our skid packages are not just assembled; they are masterfully crafted for precision. The alignment of the pump with the diesel engine or electric motor is flawless, ensuring direct and seamless operation. Downtime is not in our vocabulary.
Durability Meets Space Efficiency
Robust Foundations for Longevity
At the core of our skid packages lies a one-piece base plate, complete with anchor bolt holes. This design choice enhances stability, ensuring that your fire protection system remains steadfast in the face of adversity.
Built to Last
Our skid packages are constructed using engineered, coated, hot-rolled mild steel, providing resistance against corrosion and abrasion. Additionally, a heavy fabricated C-Channel Structure ensures the perfect alignment of the pump with the diesel engine or electric motor.
Space-Saving Design
In today's world, space is a valuable commodity. AL ADRAN's skid packages feature a compact design with a minimal footprint, ideal for retrofitting into existing facilities. No need to sacrifice space for safety.
FIRE PUMP SYSTEM COMPONENTS
DIESEL TANKS
FIRE PUMP CONTROLLERS
DIESEL TANKS
All steel above ground tanks for flammable and combustible
liquid are assembled and tested to all requirements as follows
ANSI/UL-142-Complaint. Installation standard compliance to NFPA 30, NFPA30A and NFPA31 Fire pump supplier
Primary Containment Tanks: Horizontal Cylindrical Construction (Capacity upto 75000 Gallon) Vertical Cylindrical
All steel above ground tanks for flammable and combustible
liquid are assembled and tested to all requirements as follows
ANSI/UL-142-Complaint. Installation standard compliance to NFPA 30, NFPA30A and NFPA31 Fire pump supplier
Primary Containment Tanks: Horizontal Cylindrical Construction (Capacity upto 75000 Gallon) Vertical Cylindrical Construction (Capacity upto 60000 Gallon) Rectangular Construction (Capacity upto 550 Gallon) Secondary Containment Tanks Horizontal Cylindrical Construction (Capacity upto 75000 Gallon) Vertical Cylindrical Construction (Capacity upto 60000 Gallon)
JOCKEY PUMPS
FIRE PUMP CONTROLLERS
DIESEL TANKS
Jockey pumps are small, motor driven pumps used in conjunction with
main fire pumps to compensate for minor leaks in the fire protection
system and automatically maintain stand-by pressure. This reduces
wear on the main pump and controller caused by unnecessary,
frequent operation. Jockey Pump controllers are available for across
the-line starting. Fire pump supplier
FIRE PUMP CONTROLLERS
FIRE PUMP CONTROLLERS
FIRE PUMP CONTROLLERS
- ELECTRICAL PUMP CONTROLLER
- DIESEL PUMP CONTROLLER
- JOCKEY PUMP CONTROLLER
- ALARM PANEL
Fire pump supplier
All Fire Pump Controllers are factory assembled, wired, tested as a
unit and comply with all requirements of the latest edition of NFPA-
20 (Centrifugal Fire Pumps) and NFPA-70 (National Electrical Code).
Controllers are listed by Underwriters
- ELECTRICAL PUMP CONTROLLER
- DIESEL PUMP CONTROLLER
- JOCKEY PUMP CONTROLLER
- ALARM PANEL
Fire pump supplier
All Fire Pump Controllers are factory assembled, wired, tested as a
unit and comply with all requirements of the latest edition of NFPA-
20 (Centrifugal Fire Pumps) and NFPA-70 (National Electrical Code).
Controllers are listed by Underwriters Laboratories, Inc., in accordance
with UL218, Standard for Fire Pump Controllers, CSA, and Standard
for Industrial Control Equipment (CUL) and approved by Factory Mutual (FM). All controllers are Y2K compliant. This component plays a vital role in operation of fire pumps as it controls the entire system. It is selected as per customer choice if any, otherwise it can be either TORNATECH, OR EATON.
Fire Pump Supplier
Top NAFFCO Fire Pump Supplier - Reliable Fire Pumps & Equipment
Looking for a dependable NAFFCO fire pump supplier? Our experts provide high-quality fire pumps and equipment, ensuring your safety. Contact us today
- 300 GPM @ 5 Bar: NPS300/5-EDJ100-103
- 300 GPM @ 6 Bar: NPS300/6-EDJ100-103
- 300 GPM @ 7 Bar: NPS300/7-EDJ100-103
- 300 GPM @ 8 Bar: NPS300/8-EDJ100-108
- 300 GPM @ 9 Bar: NPS300/9-EDJ100-108
- 300 GPM @ 10 Bar: NPS300/10-EDJ100-108
- 300 GPM @ 12 Bar: NPS300/12-EDJ100-108
- 350 GPM @ 5 Bar: NPS350/5-EDJ100-103
- 350 GPM @ 6 Bar: NPS350/6-EDJ100-103
- 350 GPM @ 7 Bar: NPS350/7-EDJ100-108
- 350 GPM @ 8 Bar: NPS350/8-EDJ100-108
- 350 GPM @ 9 Bar: NPS350/9-EDJ100-108
- 350 GPM @ 10 Bar: NPS350/10-EDJ100-108
- 350 GPM @ 12 Bar: NPS350/12-EDJ200-108
- 400 GPM @ 5 Bar: NPS400/5-EDJ100-103
- 400 GPM @ 6 Bar: NPS400/6-EDJ100-108
- 400 GPM @ 7 Bar: NPS400/7-EDJ100-108
- 400 GPM @ 8 Bar: NPS400/8-EDJ100-108
- 400 GPM @ 9 Bar: NPS400/9-EDJ100-108
- 500 GPM @ 6 Bar: NPS500/6-EDJ100-108
- 500 GPM @ 7 Bar: NPS500/7-EDJ100-108
- 500 GPM @ 8 Bar: NPS500/8-EDJ100-108
- 500 GPM @ 9 Bar: NPS500/9-EDJ100-108
- 500 GPM @ 10 Bar: NPS500/10-EDJ100-108
- 500 GPM @ 11 Bar: NPS500/11-EDJ100-108
- 500 GPM @ 12 Bar: NPS500/12-EDJ200-108
- 500 GPM @ 13 Bar: NPS500/13-EDJ100-108
- 600 GPM @ 10 Bar: NPS600/10-EDJ100-108
- 600 GPM @ 11 Bar: NPS600/11-EDJ100-108
- 600 GPM @ 14 Bar: NPS600/14-EDJ-108
- 650 GPM @ 7 Bar: NPS650/7-EDJ100-108
- 750 GPM @ 7 Bar: NPS750/7-EDJ100-108
- 750 GPM @ 8 Bar: NPS750/8-EDJ200-108
- 750 GPM @ 9 Bar: NPS750/9-EDJ200-108
- 750 GPM @ 10 Bar: NPS750/10-EDJ100-108
- 750 GPM @ 11 Bar: NPS750/11-EDJ200-108
- 750 GPM @ 12 Bar: NPS750/12-EDJ200-108
- 750 GPM @ 13 Bar: NPS750/13-EDJ200-108
- 750 GPM @ 14 Bar: NPS750/14-EDJ-108
- 750 GPM @ 15 Bar: NPS750/15-EDJ-108
- 750 GPM @ 18 Bar: NPS750/18-EDJ-108
- 1000 GPM @ 8 Bar: NPS1000/8-EDJ200-108
- 1000 GPM @ 10 Bar: NPS1000/10-EDJ200-108
- 1000 GPM @ 12 Bar: NPS1000/12-EDJ200-108
- 1250 GPM @ 7 Bar: NPS1250/7-EDJ300-108
- 1250 GPM @ 10 Bar: NPS1250/10-EDJ300-108
- 1500 GPM @ 10 Bar: NPS1500/10-EDJ300-108
- 2200 GPM @ 10 Bar: NPS2200/10-EDJ300-108
- 2500 GPM @ 10 Bar: NPS2500/10-EDJ500-108
- 2500 GPM @ 12 Bar: NPS2500/12-EDJ500-108
Note: Fire pump sets are available for other duty points and higher ranges as well.
